活動法蘭式熱電阻
發布時間:2019-06-21 訪問量：801
|
型號 |
分度號 |
測溫范圍 ℃ |
熱響應時間 |
規 格 | |
| d | L | ||||
| WZP-320 WZP2-320 |
Pt100 |
-200~500 |
＜90s |
φ16 |
300 350 400 450 500 550 650 900 1150 1650 2150 |
| WZP-320G WZP2-320G |
＜24s |
||||
| WZP-321 WZP2-321 |
＜90s |
φ12 |
|||
| WZP- 321G WZP2-321G |
＜24s |
||||
| WZP-330 WZP2-330 |
＜90s |
φ16 |
|||
| WZP- 330G WZP2-330G |
＜24s |
||||
| WZP- 331 WZP2-331 |
＜90s |
φ12 |
|||
| WZP- 331G WZP2-331G |
＜24s |
||||
| WZC-320G |
Cu50 Cu100 |
-50~100 |
＜120s |
φ16 |
|
| WZC-320 | ＜40s | ||||
| WZC-330 | ＜120s | ||||
| WZC-330G | ＜40s | ||||
| WZC-321 | ＜120s |
φ12 |
|||
| WZC-321G | ＜40s | ||||
| WZC-331 | ＜120s | ||||
| ＜40s | |||||
1）型號320、321為防噴式，防護等級 IP65;型號330、331為防水式，防護等級 IP55
2）保護管材質為1Cr18Ni9Ti,其余材質根據協議訂貨
